Walkie Stacker
Compact | Cost-Effective | High Maneuverability
Globe MachMovers is a leading Walkie Stacker manufacturer in India, offering reliable, easy-to-use, and cost-effective material handling solutions for warehouses, distribution centers, and retail operations. Designed for efficiency in confined spaces, our Walkie Stackers combine electric lifting with manual or electric propulsion, making them ideal for light to medium-duty stacking operations.
What is a Walkie Stacker?
The Walkie Stacker, also known as a pedestrian-controlled stacker, is operated by walking alongside the machine. It offers excellent maneuverability in tight aisles and is perfect for indoor use. With battery-powered lifting, the stacker reduces manual strain and increases productivity in vertical material handling tasks.
Technical Specifications
| Product Type | Walkie Electric Stacker |
|---|
| Operation Type | Walk-Behind (Pedestrian Controlled) |
|---|
| Lifting Capacity | 1000 kg / 1500 kg / 2000 kg |
|---|
| Lifting Height (Max.) | 1600 mm / 2500 mm / 3000 mm / 3500 mm / 4500 mm |
|---|
| Lowered Fork Height | 85 mm to 100 mm |
|---|
| Fork Length | 1000 mm / 1150 mm |
|---|
| Fork Width (Adjustable) | 300 mm to 850 mm |
|---|
| Mast Type | Single / Duplex / Triplex |
|---|
| Overall Width | 800 mm to 1000 mm |
|---|
| Drive Motor Power | 0.75 kW to 1.2 kW |
|---|
| Lift Motor Power | 1.5 kW to 2.2 kW |
|---|
| Battery Voltage | 24V DC |
|---|
| Battery Capacity | 120 Ah to 280 Ah (Lead Acid / Lithium-Ion) |
|---|
| Charger | In-built / External (Automatic, 24V/30A or higher) |
|---|
| Travel Speed (Laden/Unladen) | 3 – 6 km/h |
|---|
| Lifting Speed (Laden/Unladen) | 80 – 120 mm/sec |
|---|
| Lowering Speed | Smooth Controlled Descent |
|---|
| Turning Radius | ~1350 mm (varies with model) |
|---|
| Braking System | Electromagnetic Brake |
|---|
| Wheel Material | Polyurethane / Nylon |
|---|
| Control System | Multi-function Tiller Handle with Forward/Reverse & Horn |
|---|
| Safety Features | - Emergency Stop
- Belly Button Reverse Switch
- Battery Indicator |
|---|
| Surface Finish | Powder Coated / Industrial Grade Paint |
|---|
| Usage/Application | Pallet Stacking, Loading/Unloading, Horizontal Transport in Aisles |
|---|
Key Features
- Load capacity: 1000 kg to 2000 kg
- Lifting height: Up to 5000 mm
- Battery-operated lift with manual or powered travel
- Compact and ergonomic design for narrow aisle operation
- Intuitive control handle with safety features
- Maintenance-free AC drive motor (in electric travel models)
- Strong mast structure and durable frame
Applications
- Pallet stacking in narrow aisles
- Material transfer in small warehouses
- Shelf loading/unloading in retail backrooms
- Handling operations in cold storage units
- Stacking and order picking in low-volume areas
Industries We Serve
- Warehousing & Logistics
- Retail & FMCG
- Pharmaceuticals & Healthcare
- Food & Beverage
- Packaging & Printing
- Electronics & Appliances
Benefits of Globe MachMovers’ Walkie Stackers
- Energy-efficient and emission-free indoor operation
- Reduced physical strain and improved worker comfort
- Enhanced safety features and ergonomic controls
- Compact footprint for tight spaces
- Battery options with long operational runtime
- Reliable performance with low maintenance needs
Why Choose Globe MachMovers?
- Space-Saving Design: Perfect for operations in confined or narrow spaces
- Ease of Use: Simple controls with enhanced operator visibility and maneuverability
- Custom Options: Available in standard and straddle leg variants
- Reliable Performance: Designed for durability and long operational life
- Nationwide Support: Prompt delivery, service, and spare part availability across India
Request Your Quote Today
Looking for a compact and efficient stacking solution?
Choose Globe MachMovers – your trusted Walkie Stacker manufacturer and supplier in India.
Enhance warehouse efficiency with smart, space-saving handling equipment.
