Electric Stacker
Efficient | Ergonomic | Eco-Friendly Material Handling Solutions
Globe MachMovers is a trusted name among the top Electric Stacker manufacturers in India, offering a wide range of electric stackers designed to enhance productivity and ensure safe material handling across various industries. Built for performance, precision, and operator comfort, our electric stackers are ideal for lifting, stacking, and transporting palletized loads within warehouses, factories, and logistic centers.
What is an Electric Stacker?
An Electric Stacker is a fully battery-operated lifting and transportation equipment used for pallet handling and stacking. It eliminates manual lifting and provides smooth, quiet, and emission-free operation—making it ideal for indoor industrial use where efficiency, ergonomics, and environmental friendliness are a priority.
Technical Specifications
| Product Type | Fully Electric Stacker |
|---|
| Lifting Capacity | 1000 kg / 1500 kg / 2000 kg |
|---|
| Lifting Height (Max.) | 1600 mm / 2500 mm / 3000 mm / 3500 mm / 4500 mm |
|---|
| Lowered Fork Height | 85 mm to 100 mm |
|---|
| Fork Length | 1000 mm / 1150 mm |
|---|
| Fork Width (Adjustable) | 300 mm to 850 mm |
|---|
| Mast Type | Single / Duplex / Triplex |
|---|
| Closed Mast Height | Varies with model (e.g. 1980 mm for 1600 mm lift) |
|---|
| Lift Motor Power | 1.5 kW to 2.2 kW |
|---|
| Travel Motor Power | 0.75 kW to 1.2 kW (for ride-on models) |
|---|
| Power Supply | 24V DC Battery Operated |
|---|
| Battery Capacity | 100 Ah to 280 Ah (Lead Acid / Lithium-Ion) |
|---|
| Charger Type | Built-in / External, Automatic 24V/20A or as required |
|---|
| Lifting Speed (Laden/Unladen) | 80 – 120 mm/sec |
|---|
| Lowering Speed | Controlled via valve or electric control |
|---|
| Travel Speed (Laden/Unladen) | 3 – 5 km/h |
|---|
| Turning Radius | Approx. 1350 mm (varies by model) |
|---|
| Wheel Material | Polyurethane / Nylon |
|---|
| Brake System | Electromagnetic Brake |
|---|
| Steering Type | Manual Steering / Electric Power Steering (on ride-on types) |
|---|
| Control Mode | Electric Push Button / Thumb Control Switch |
|---|
| Display Panel | Battery Level, Hour Meter, Error Code Display (on advanced models) |
|---|
| Surface Finish | Powder Coated / Painted |
|---|
| Safety Features | - Emergency Stop
- Horn
- Reverse Movement Buzzer
- Battery Discharge Indicator |
|---|
| Usage/Application | Warehouse Stacking, Pallet Movement, Loading & Unloading |
|---|
Key Features
- Load capacity up to 2000 kg
- Lifting height up to 5500 mm
- Maintenance-free AC drive motor
- Intelligent control system for precise handling
- Ergonomic tiller arm with safety features
- Long-lasting battery with fast charging options
- Compact design for narrow aisle operation
Applications
- Warehouses and Distribution Centers
- Retail Stores and Hypermarkets
- Cold Storage and Food Processing Units
- Pharmaceutical & Chemical Industries
- Automotive and Engineering Workshops
- E-commerce Fulfillment Centers
Industries We Serve
- Logistics & Supply Chain
- Manufacturing & Assembly Units
- FMCG & Packaging
- Textile & Garment
- Electronics & Electricals
- Beverage & Dairy Industries
Sustainability & Energy Efficiency
Our electric stackers offer a zero-emission solution for indoor material movement. Designed to consume less power, reduce operational noise, and lower maintenance costs, they are an ideal choice for environmentally conscious businesses aiming for green operations.
Why Choose Electric Stackers from Globe MachMovers?
- Proven Reliability: Robust build quality with long operational life
- Operator-Friendly Design: Enhanced safety and ergonomic controls
- Nationwide Support: Pan-India service network and spare parts availability
- Customization Available: Tailored solutions to meet unique application needs
- Compliance Certified: CE marked and adheres to global safety standards
Request Your Quote Today
Looking for reliable Electric Stackers for your facility?
Contact Globe MachMovers – Your trusted partner in electric stacker manufacturing and supply.
Boost your warehouse efficiency today!
