Single Girder EOT Crane
Reliable Overhead Lifting | Cost-Effective Design | Precision Handling
Globe MachMovers is a renowned Single Girder EOT Crane manufacturer in India, offering high-performance, reliable, and economical lifting solutions for a wide range of industrial applications. Our single girder cranes are ideal for material handling in workshops, warehouses, manufacturing units, assembly lines, and fabrication shops.
What is a Single Girder EOT Crane?
A Single Girder EOT (Electric Overhead Traveling) Crane is an overhead crane that consists of a single main girder supported on end carriages, with a hoist (usually electric wire rope or chain type) traveling on the lower flange of the girder. It is suitable for light to medium-duty lifting tasks, offering excellent load control, reduced structure weight, and cost-effective performance. These cranes are available in top-running and under-slung models and are designed in compliance with IS/ISO standards for safety and durability.
Technical Specifications
| Crane Type | Single Girder EOT Crane |
|---|
| Capacity | 0.5 Ton to 20 Ton (Customizable as per requirement) |
|---|
| Span | Up to 30 meters (Customizable) |
|---|
| Lifting Height | Up to 20 meters (Customizable) |
|---|
| Duty Class | Class I (Light Duty) to Class IV (Heavy Duty) – IS 3177 / IS 807 |
|---|
| Crane Configuration | Top Running / Under Slung |
|---|
| Hoist Type | Electric Wire Rope Hoist / Chain Hoist |
|---|
| Hoisting Speed | 3 – 8 m/min (variable depending on capacity) |
|---|
| Cross Travel Speed | 10 – 25 m/min |
|---|
| Long Travel Speed | 10 – 40 m/min (optional VFD for variable speed) |
|---|
| Control Method | Pendant Control / Wireless Radio Remote / Cabin Control (optional) |
|---|
| Power Supply | 3 Phase, 415V ±10%, 50 Hz |
|---|
| Control Voltage | 24V / 48V / 110V |
|---|
| Crane Bridge Material | Rolled Section / Plate Box Type Fabrication |
|---|
| End Carriages | Fabricated Steel Construction with Machined Wheels |
|---|
| Wheel Material | EN8 / EN9 / Forged Steel |
|---|
| Gearbox Type | Helical / Spur Gearboxes (with Hardened & Ground Gears) |
|---|
| Brake Type | Electromagnetic / Hydraulic Thruster Brake / Disc Brake |
|---|
| Painting / Finish | Industrial Grade Primer + Top Coat / Powder Coated Finish |
|---|
| Safety Features | Overload Protection, Limit Switches (Hoist & Travel), Anti-collision Device |
|---|
| Standards Compliance | IS 807, IS 3177, IS 3938, IS 4137, FEM, ISO |
|---|
| Application Areas | Warehouses, Factories, Assembly Lines, Workshops, Steel Plants, Logistics Hubs |
|---|
Key Features
- Load Capacity: From 1 Ton to 20 Tons (customizable)
- Span Length: Up to 30 meters or as per requirement
- Hoist Type: Electric wire rope hoist or chain hoist
- Design Type: Top running or under-slung configurations
- Controls: Pendant control / Radio remote control / Cabin operation
- Drive Mechanism: Variable frequency drive (VFD) for smooth movement
- Safety Features: Overload limiter, limit switches, anti-collision device, emergency stop
- Compliance: Designed as per IS 3177 / IS 807 / FEM / DIN standards
Applications
- Assembly lines and fabrication shops
- Warehouse material movement
- Machine loading/unloading operations
- Tool rooms and maintenance areas
- Logistics and packaging facilities
- Light to medium manufacturing plants
Industries We Serve
- Engineering & Manufacturing
- Automotive & Aerospace
- Warehousing & Logistics
- Steel Plants & Foundries
- Construction & Infrastructure
- Power Plants & Utilities
Benefits of Globe MachMovers’ Single Girder EOT Crane
Our Single Girder EOT Cranes offer cost-effective solutions for medium-duty lifting at a lower cost than double girder cranes, a lightweight design to reduce load on building structures, efficient material handling with smooth travel and precise load positioning, low maintenance with high-quality components for a long service life, and customizable designs to suit your layout, height, and capacity requirements.
Why Choose Single Girder EOT Cranes from Globe MachMovers?
- Trusted Single Girder EOT Crane manufacturer in India
- Decades of expertise in crane design and fabrication
- Manufactured with IS-standard components and rigorous quality checks
- On-time delivery, easy installation, and reliable after-sales support
- Nationwide service and AMC options available
Looking for a dependable and affordable overhead crane solution?
Choose Globe MachMovers, your expert Single Girder EOT Crane supplier in India, and streamline your lifting operations with unmatched safety and efficiency.
Enhance your productivity with our reliable and cost-effective crane systems.
