High Lift Pallet Truck (MS/SS)
Elevated Load Handling | Ergonomic Design | Hygienic Options
Globe MachMovers is a trusted High Lift Pallet Truck manufacturer in India, offering premium-grade MS (Mild Steel) and SS (Stainless Steel) pallet trucks designed for applications where both transport and elevated positioning are essential. Our High Lift Pallet Trucks are perfect for loading/unloading tasks, feeding production lines, or acting as mobile work platforms.
What is a High Lift Pallet Truck (MS/SS)?
A High Lift Pallet Truck combines the functionality of a standard pallet jack with the added benefit of vertical lifting. Available in manual or electric lift versions, these pallet trucks can raise loads up to 800 mm, reducing worker strain and improving workflow in packaging, assembly, and material transfer areas. Our SS models are specifically suited for pharmaceutical, food, and chemical industries that require corrosion resistance and hygiene compliance.
Technical Specifications
| Model Type | High Lift Pallet Truck – Manual / Semi Electric |
|---|
| Material Options | Mild Steel (MS) / Stainless Steel (SS 304) |
|---|
| Load Capacity | 1000 kg / 1500 kg |
|---|
| Fork Length | 1150 mm (customizable) |
|---|
| Fork Width (Overall) | 520 mm / 685 mm |
|---|
| Fork Width (Individual) | 160 mm |
|---|
| Raised Height | 800 mm |
|---|
| Lowered Height | 85 mm |
|---|
| Lift Type | Manual Hydraulic / Battery Operated (optional) |
|---|
| Wheel Material | Nylon / PU / Rubber |
|---|
| Steering Wheel Size | Ø180 mm × 50 mm |
|---|
| Load Roller Size | Ø82 mm × 70 mm |
|---|
| Stabilizers | Automatic side stabilizers for high lift stability |
|---|
| Pump Type | Quick lift hydraulic pump |
|---|
| Surface Finish | Powder Coated (MS) / Buffed Mirror Finish (SS) |
|---|
| Weight (Approx.) | 120 kg – 150 kg |
|---|
| Application | Lifting loads to ergonomic working height, production & packaging lines |
|---|
Key Features
- Load capacity: 1000 kg to 1500 kg
- Lifting height: Up to 800 mm
- Available in MS (powder-coated) & SS304/SS316
- Hydraulic or semi-electric lifting options
- Fork length: 1150 mm (customizable)
- Stabilizer legs for enhanced safety at raised heights
- Ergonomic control handle with 3-position operation
- Smooth-rolling PU/nylon wheels for easy movement
Applications
- Loading/unloading at elevated platforms
- Feeding raw materials to assembly or conveyor lines
- Mobile work positioning table
- Handling palletized loads at ergonomic heights
- Warehouses, production units, and cleanroom facilities
Industries We Serve
- Pharmaceuticals & Healthcare
- Food & Beverage Processing
- Packaging & Logistics
- Chemical Manufacturing
- Electronics Assembly
- Cold Storage & Cleanrooms
Ergonomics & Safety Focus
Our High Lift Pallet Trucks help reduce bending, lifting injuries, and fatigue by allowing users to raise materials to an ergonomic working level. With sturdy stabilizers and leak-proof hydraulics, these pallet trucks offer maximum safety and performance during high-lift operations.
Why Choose High Lift Pallet Trucks (MS/SS) from Globe MachMovers?
- Heavy-Duty Build: Designed for demanding industrial use
- Ergonomic Efficiency: Reduces manual strain & increases productivity
- Corrosion-Resistant Options: SS models for hygienic environments
- Customizable Designs: Fork size, capacity, and lift height tailored to your needs
- Pan-India Support: Reliable delivery and after-sales service
Need a pallet truck that lifts more than just weight?
Choose Globe MachMovers – a leading High Lift Pallet Truck manufacturer and supplier in India.
Elevate your operations with our robust and ergonomic solutions.
