Semi Electric Drum Lifter
Efficient Lifting | Safe Handling | Cost-Effective Operation
Globe MachMovers offers highly efficient and durable Semi Electric Drum Lifters in India, designed to simplify the process of lifting, moving, and placing heavy drums with minimal manual effort. Our drum lifters combine electric-powered lifting with manual maneuvering, providing the perfect balance of power, control, and cost-effectiveness. Engineered for industrial use, our semi electric drum lifters are suitable for handling steel, plastic, or fiber drums in warehouses, manufacturing plants, chemical industries, and logistics hubs.
What is a Semi Electric Drum Lifter?
The Semi Electric Drum Lifter is built with a sturdy steel frame, an integrated electric lifting mechanism, and manual push operation for mobility. This hybrid design helps reduce operator fatigue, improves workplace safety, and increases material handling efficiency. It can safely lift and transport 210-liter drums, with lifting heights customizable as per requirement. Ideal for areas where manual lifters fall short and full electric models are not viable, this equipment offers a cost-effective and reliable solution for medium to heavy-duty drum operations.
Technical Specifications
| Model Type | Semi Electric Drum Lifter Cum Tilter |
|---|
| Operation Type | Electric Lifting / Manual Tilting & Movement |
|---|
| Drum Compatibility | 210 – 220 Litres (Steel / Plastic Drums) |
|---|
| Load Capacity | 300 kg to 500 kg (standard models) |
|---|
| Lifting Height | 1200 mm to 1600 mm (customizable) |
|---|
| Drum Rotation | Manual Rotation – 180° to 360° |
|---|
| Tilting Angle | Up to 360° (for pouring or decanting) |
|---|
| Lifting Mechanism | DC Powered Hydraulic Pump |
|---|
| Battery Type | 12V / 24V DC Maintenance-free Battery |
|---|
| Battery Capacity | 65 Ah to 100 Ah (Depending on model) |
|---|
| Charger Type | Inbuilt / External 220V Single Phase |
|---|
| Drum Gripping System | Clamp-Type or Belt & Hook System |
|---|
| Frame Material | Heavy-Duty MS (Mild Steel) |
|---|
| Surface Finish | Powder Coated / Epoxy Painted |
|---|
| Wheel Configuration | 2 Rear Fixed + 2 Front Swivel (PU / Nylon Wheels) |
|---|
| Braking System | Mechanical Brake on Wheels (optional) |
|---|
| Control Panel | Push Button for Lift / Emergency Stop |
|---|
| Dimensions (L x W x H) | Approx. 1200 mm x 850 mm x 2000 mm |
|---|
| Net Weight | 150 kg to 220 kg |
|---|
| Applications | Drum Lifting, Tilting, Pouring into Reactors or Mixers |
|---|
| Industries Served | Chemicals, Paints, Pharmaceuticals, Food & Beverages, Oil & Lubricants |
|---|
Key Features
- Lifting Capacity: Up to 300 kg
- Drum Types: Compatible with MS/SS/plastic 210-liter drums
- Lift Height: Up to 1600 mm (customizable)
- Operation: Electric lifting + manual movement
- Battery: Long-lasting battery with charger
- Structure: Powder-coated heavy-duty steel frame
- Wheels: PU/Nylon wheels with brakes for easy mobility and safety
- Safety: Mechanical drum lock, overload protection, and ergonomic handle
Applications
- Drum loading/unloading from pallets or trolleys
- Drum stacking in vertical storage
- Feeding drums into mixers or reactors
- Drum movement in production or filling lines
- Chemical and pharmaceutical drum handling
Industries We Serve
- Chemical & Petrochemical Plants
- Food & Beverage Processing
- Pharmaceuticals & Cosmetics
- Paint & Coating Industries
- Warehousing & Packaging Units
- Oil, Lube, and Adhesive Manufacturing
Benefits of Globe MachMovers’ Semi Electric Drum Lifter
Our Semi Electric Drum Lifters are designed to increase productivity with fast and smooth lifting, reduce manual strain, and ensure safe drum handling. Compact and mobile, they navigate tight warehouse aisles easily. Offering a cost-effective alternative to full electric models, they feature a secure drum clamping system, stable lifting structure, and low-maintenance battery operation.
Why Choose Semi Electric Drum Lifters from Globe MachMovers?
- Renowned Semi Electric Drum Lifter manufacturer in India
- Custom-built models available for various drum sizes and applications
- Pan-India delivery and after-sales service support
- Trusted by manufacturing, warehousing, and chemical companies nationwide
Ready to simplify your drum handling process?
Contact Globe MachMovers for a high-performance Semi Electric Drum Lifter in India, designed for safe and efficient industrial drum movement.
Streamline your operations with our reliable and cost-effective solutions.
