Hydraulic Scissor Lift
Heavy-Duty | Reliable | Precision-Lifting | Built for Industrial Material Handling & Maintenance
At Globe Mach Movers, we specialize in designing and manufacturing high-performance Hydraulic Scissor Lifts for safe, smooth, and efficient vertical lifting in industrial, commercial, and maintenance applications.
Engineered with robust structural steel, precision hydraulic cylinders, and advanced control systems, our scissor lifts are trusted for handling heavy loads, personnel access, and equipment at varying heights with maximum safety and reliability.
Whether for loading/unloading, mezzanine floor access, assembly line positioning, or facility maintenance, our lifts offer durability, efficiency, and global-standard performance.
Product Overview
Our hydraulic scissor lifts are available in stationary, mobile, and pit-mounted models, with multiple configurations tailored to site requirements.
From ground-level to elevated platforms, our hydraulic lifts ensure safe material movement, operator access, and space optimization.
- Stationary Lifts – For fixed installation (loading docks, warehouses, production lines).
- Mobile Lifts – Towable or self-propelled units for flexible use across work zones.
- Pit-Mounted Lifts – Flush-fit design for seamless ground-level access.
Each lift is powered by high-efficiency hydraulic pumps and precision cylinders for smooth, controlled, and low-noise lifting.
Technical Specifications
| Capacity | 300 kg – 10,000 kg |
|---|
| Maximum Lifting Height | 0.8 m – 12 m (customizable) |
|---|
| Lowered Height | 180 – 500 mm |
|---|
| Platform Size (L×W) | 800×500 mm to 6000×3000 mm |
|---|
| Lifting Mechanism | Hydraulic cylinders with check valve & flow control |
|---|
| Power Source | Electric (AC 220V/380V, 50Hz/60Hz, 1PH/3PH), Battery (24V/48V DC), or Manual |
|---|
| Control System | Push-button pendant, foot switch, or wireless remote |
|---|
| Safety Features | Emergency stop, overload protection, hose burst valve, toe guards, limit switches, guardrails (for personnel models) |
|---|
| Surface Finish | Epoxy powder-coated / hot-dip galvanized (for outdoor use) |
|---|
| Mobility Options | PU wheels, castor wheels, tow-bar, or self-propelled drive |
|---|
| Mounting Options | Surface-mounted / Pit-mounted |
|---|
| Operating Temperature | -10°C to +50°C |
|---|
| Compliance | CE, EN 1570, ANSI/ASME standards |
|---|
Key Features
- Smooth vertical lifting via precision hydraulic cylinders
- Wide capacity range (300 kg – 10 tons)
- Customizable platform sizes and heights
- Low-noise & energy-efficient operation
- Safety-first design (emergency stop, overload & anti-drop protection)
- Available in manual, AC, DC battery, or self-propelled models
- Low maintenance with long service life
Applications
- Loading & Unloading at warehouses, docks, and production units
- Assembly Line Integration in manufacturing and engineering plants
- Maintenance Access for equipment and facility servicing
- Floor-to-Floor Transfers in logistics & retail facilities
- Personnel Lifting with guardrails for safe elevated access
- Heavy Material Handling in pharma, packaging, FMCG, and automotive
Industries We Serve
- Manufacturing & Engineering
- Warehousing & Logistics
- Automotive & Aerospace
- Pharmaceuticals & Packaging
- Retail, FMCG & Distribution
- Airports, Malls & Facility Management
